Customized Size Zirconia Ball Mill Jar Zirconia Ceramic Laboratory Grinding Pot With Lid

Brand Name : YH

Model Number : YH -Z

Certification : ISO

Place of Origin : CHINA

MOQ : 10

Price : Negotiated

Payment Terms : L/C,T/T,Western Union

Supply Ability : 5000pcs per month

Delivery Time : 15-20days

Packaging Details : By wooden case

Tensile Strength : 200 MPa

Applications : Industrial ceramic

Type : ceramic crucible

Electrical Resistivity : 10¹⁴ to 10¹⁵ Ω·cm

Dielectric Constant : 9.8 to 10.2

Low Dielectric Loss : 0.0002

Thermal Conductivity : 20 to 30 W/m·K

Dimensional Tolerance : ±0.001 mm

Application : Industrial Ceramic

Compressive Strength : Up to 3000 MPa

Size : Customized

Melting Point : 2040°C

Method : lsostatic presure

Temperature Resistance : Up to 1450°C

Contact Now

Zirconium Oxide Ceramic Planetary Ball Mill Jar

Zirconia Ceramic Laboratory Grinding Pot With Lid

Tired of Grinding Contamination and Distorted Data?

Our Premium Zirconia (YSZ) Grinding Jar is tailored to tackle the core challenges in laboratory milling.

Designed for professionals in research and quality control who pursue ultimate purity and grinding efficiency,

it enables high-intensity grinding without wear, preserving the original state of every sample with its contamination-free performance.

Metallic ion contamination from stainless steel and rapid wear of alumina both compromise experimental accuracy.

Yttria-Stabilized Zirconia (YSZ) leverages extraordinary hardness and chemical inertness to handle hard materials effortlessly,

eliminating wear-induced contamination and ensuring trustworthy analytical data

—making it the unrivaled choice for high-end sample processing.

Customized Size Zirconia Ball Mill Jar Zirconia Ceramic Laboratory Grinding Pot With Lid

Technical Specifications

* Material: Yttria-Stabilized Zirconia (Y₂O₃-ZrO₂)* Density: ≈6.0 g/cm³
* Vickers Hardness: >1200 HV
* Max. Operating Temperature: 1000 °C
* Sealing: Silicone O-ring (standard), PTFE gasket available upon request

			* Available Sizes: 50mL, 100mL, 250mL, 500mL, 1L
* Recommended Grinding Media: Zirconia grinding balls (same material) for optimal performance and minimal wear.

Applications

* Geology & mineral sample preparation

* Nanomilling of ceramics, glass, and pigments

* Battery material R&D (e.g., cathode/anode powders like NMC, LFP)

* Fine grinding of metal alloys

* Mixing of polymer composites


Parameters of Zirconia Mill Jar

Specifications (ml)	External Diameter (mm)	Inner Diameter (mm)	Height (mm)
50ml	55	38	38
100ml	65	50	50
250ml	92	74	74
500ml	100	84	84
1000ml	128	108	108
1500ml	132	112	112
2000ml	158	134	134
3000ml	158	138	225
Remarks:Size deviation within ±2mm. We offer tailored solutions in accordance with customer designs and requirements.

Customized Size Zirconia Ball Mill Jar Zirconia Ceramic Laboratory Grinding Pot With Lid

Features:

High cost-effective, low wear and long lifetime

High specific gravity, high efficiency

Highly wear resistant to acid and solvents

Highly polished, smooth, easy to clean, low abrasion to the equipment

High mechanical strength, good toughness, impact resistance, no broken beads

Mainly used for lab planetary ball mill machines

Customized Size Zirconia Ball Mill Jar Zirconia Ceramic Laboratory Grinding Pot With Lid

Product packaging

Zirconia Grinding Jar Packaging Options:

Single Unit Pack: ardboard box with foam,Suitable for samples and small orders;

Bulk Pack: * Sturdy box with foam dividers,For regular procurement needs;

Custom Pack: For special requirements and large purchases

FAQ

Q1. Do you provide product samples?

Yes, we provide samples subject to availability. A nominal sample fee may apply in some cases, and shipping costs are borne by the customer.

Q2. What are your accepted payment methods?

We accept T/T (bank transfer) in advance, Western Union, Alipay, and PayPal.

Q3. What is your typical delivery lead time?

Lead times vary depending on product requirements, including material selection, dimensions, and specific manufacturing processes.

Q4. Do you perform quality inspection before shipment?

Yes, we conduct 100% inspection of all goods prior to delivery to ensure they meet specified standards.

Q5. What other ceramic materials do you offer?

We supply a range of advanced ceramic materials, including Alumina, Zirconia, Aluminum Nitride,Boron Nitride, Silicon Nitride, Machinable Glass Ceramic, and related specialized ceramics.
